Ok I just can't see this questions I don't want an answer I just whant an explation on how to do it. if you can respond today it would be great thanks! an simple drawing like I did would be great thanks!

a block weighing 100 newtons is positioned on a incline that makes an angle of 30 degrees with the horizontal. The friction force between the block and the incline is 10 newtons. A force of 120 newtons is applied by pulling on a rope that makes an angle of 30 degrees with the incline as shown in attachment.

1. Determine the components of the block's weight parallel to incline (is that Fg?)

2. Determine the magnitude and direction of the componet of the tension that is useful in moving the block up the incline. (tension)

3. Determine the magnitude and direction of the block acceleration.

a block weighing 100 newtons is positioned on a incline that makes an angle of 30 degrees with the horizontal. The friction force between the block and the incline is 10 newtons. A force of 120 newtons is applied by pulling on a rope that makes an angle of 30 degrees with the incline as shown in attachment.

1. Determine the components of the block's weight parallel to incline (is that Fg?)

2. Determine the magnitude and direction of the componet of the tension that is useful in moving the block up the incline. (tension)

3. Determine the magnitude and direction of the block acceleration.
